0-99 Celsius Intelligent Thermostat with Waterproof Probe Adjustable Electronic Digital Display Temperature Controller Socket

Waterproof probe is suitable for lower than 80 degree.And it can detect temperature in air.It is also suitable for indoor ventilation, sprouting seeds breeding, breeding incubator and so on.

Product parameters:

Operating voltage:VAC220V / 50 Hz

Temperature control: 0-99 degree celsius
Load power: 6A resistance (load)
Installation dimensions (mm) : 138 * 98 * 43
Suitable for equipment under the power 1.2 KW connection to use! (high power equipment can be used in combination with 220 v ac contactor coil and contactor in buying)


Product features:
1. Can be set at will according to your need start temperature (0-99degree) and temperature (0-99degree) stop and automatic opening and closing of various electrical equipment power supply
2. Temperature digital display, intuitive readings, the operation is simple
3. Using a new type of temperature sensor, magnetic sensitive reaction, high precision, the sensor can be based on user need to connect, does not affect the accuracy
4. Easy installation, without changing plumbing, floor heating, electric heating pipes and lines,it can be easily connected with metal pipes, etc
5. Adopts American microcomputer chip, high integration, digital programming, control precision, strong anti-jamming capability, protection function:
a. The anti-freezing function: when the boiler water to below 3 degrees Celsius, mandatory start circulating pump, prevent freezing pipes.
b. Overtemperature alarm function: such as system inner loop water temperature over 90 degree, temperature controller and the digital tube twinkle issued a ringing, prompt the user processing in a timely manner.

6. USES: applicable to the boiler, water pump, water heater, electric heating equipment, hot water heating, geothermal membrane, floor heating, heating cable, electricity, heating, hot and cold kang ventilator, fish tank, aquarium, chamber, incubator, farms, breeding strains fermentation temperature control and accelerating seed germination.

Operation method:
Because of its heat and cooling two needs, so our thermostat "hot start" and "geothermal start" two kinds of operating mode.
1. The temperature Settings: "start temperature" and "stop" temperature setting respectively. Press "down" or "up" "arrow", and start setting up the "start temperature" and "stop" temperature, when the temperature of the set temperature reach requirements, this time the temperature of the set temperature for you.
2. High temperature activation: set to start "temperature" is greater than the "stop" temperature, temperature controller is in a state of "hot start". Settings, for example, "stop" temperature is 20degree, "start temperature"  of 30degree, so when the measured temperature at 30degreeor higher than 30degree, the machine open, run indicator (green) on, the power supply socket. When the measured temperature drops to 20degree, the machine shut down, the standby indicator (red) on a socket power outages at this time. (used for cooling equipment, heating circulation pump, etc.)
3. Low temperature start, set to start "temperature" less than "stop" temperature, thermostat in a state of "cold start". For example: "stop setting" for 30degree, "start temperature"  is 20degree, and then when the measured temperature is 20degreeor less than 20degree, the machine open, run indicator (green) on, the power supply socket at this time. When the measured temperature rise or higher than 30  to 30degree, the machine shut down, the standby indicator (red) on a socket power outages at this time. (usually for heating heating device)
Set memory function: temperature controller will store your Settings, ensure Settings when the power is not lost, no other Settings.
