55 Inch IR multi Touch Screen Panel without glass - 10 points

Technical specification of IR Touch screen:

Touch method:Finger, pen or any opaque object

Accuracy:1 mm

Touch resolution rate:4096 * 4096 pixel

Response speed:< 16 ms

Scanning speed:120 cycles/second

Transparency:> 92%

Intensity of touch:Over 60,000,000 single point touch

Operating Tem/Hum:-10 - +50   20---85% RH

Storage Tem/Hum:-30 - +60   0--- 95% RH

Type of support screen:LCD/PDP/CRT/PRT

Environment operable:Operable in various light conditions, indoor or outdoor

Degree of protection:IP 68 standard

Interface:RS232, USB or optional

Sensor:Infrared rays

OS compatible:Windows 7/2000/XP/Vista, Linux,

Certifications:CCC, CE, ROHS


Product Description:

Infrared(IR) touch screen operate on the mechanism of infrared LEDs arranged in arrays on two adjacent bezel edges of the PCB with photo sensors placed on the two opposite edges functioning as transmitters and receivers. The LEDs emit infrared rays simultaneously to form a grid of rays across the display. When the user wishes to send a signal through touch, he/she can do so by interrupting the light beams with a physical object. Since every infrared LED is independent, the touch screen is able to achieve positioning by analyzing the decrease in light at the corresponding photo sensors. The signal is then processed by the control circuitry and sent to the PC for the coordinates of the touch event to be displayed on screen or to be utilized by other software for relevant signal operation.

Advantage:

--10-touch

-- IP65 Available
--Support zoom in/out, display rotation
--Withstands severe environments
--Stable, no-drift calibration performance
--Vandal- and abrasion-resistant screens, ideal for rugged applications
--Parallax-free performance for LCD displays
--Sealable against contaminants
--Operable in various light conditions, indoor and outdoor

IR(Infrared) multi touch frame
1.Uniform resolution
2.Easy to install
3.Multi touch
4.Resistant to light interference

IR(Infrared) Multi Touch Frame

Features :

Dust and water proofing, anti-vandal;

Stable and no drift;

No light spots;

High durability and quick response to touch of any opaque object;

Wide range of temperature;

Transparency and high-resolution;

Applications of IR Touch screen:

Interactive Table;
Interactive Wall;

Multi Touch Screen;

Multi Touch Monitor;

All-in-One;

Interactive Media.

Industry control system;

Indoor/ our door kiosks,

Medical and healthcare kiosks;

Gas station

Self- service terminal

ATM

Queuing system;

Voting machine;

In vehicle and transportation;

exhibition;

Package:
