Описание товара
UNI-T LM520G Laser Level 2 Lines 360 degree Self-leveling Cross Laser Level Green Lines Laser Level
Introduction
These series products adopt diode laser beam, the waveform length of which is 635nm. The level laser can generate two or more laser sectors and one plump down point. The sector is formed by one horizontal beam and one or more vertical beams that is reflected on the wall. The included angle of every two vertical beams is 90#730. The focus of those beams is called Zenith.
- Automatic self-leveling
- Indoor and outdoor(long distance) mode
- 360#730 rotatable ; Adjustable structure for accurate targeting
- Water-proof, dirt-proof, sensitive buttons
Structure
- Vertical beam button
- Horizontal beam button
- Bubble vials
- Outdoor mode button
- Vertical laser emission window
- Horizontal laser emission window
- Power switch/lock
- Adjustable bracket#8203
|
Model |
LM520G |
LM530G |
LM550G |
|
Laser waveform length |
532nm |
||
|
Laser power |
<1 mW |
||
|
Laser grade |
CLASS II |
||
|
Laser line |
2 |
3 |
5 |
|
Plump down point |
radic (waveform length=650nm) |
||
|
Laser strengthening point |
radic |
||
|
Horizontal accuracy |
plusmn1mm/7m |
||
|
Vertical accuracy |
plusmn1mm/7m |
||
|
Orthogonality accuracy |
90#730plusmn60rdquo |
||
|
Plumb down point accuracy |
plusmn0.5mm/1.5m |
||
|
Zenith accuracy |
NA |
plusmn1mm/7m |
|
|
Emission angle |
Vertical linege110#730, horizontal linege130#730 |
||
|
Operation distance |
Indoor operating radiusasymp10m; With corresponding laser detector, operating radius=50m |
||
|
Self-leveling |
Gravity pendulum-magnetic damp |
||
|
Leveling range |
plusmn2.5 #730 |
||
|
Outdoor mode |
radic |
||
|
Battery type |
Polymer lithium battery |
||
|
Battery capacity (mAh) |
1050mAh(LM520) 1800mAh(LM530 LM550) |
||
|
Working hours |
About 6 hours (with all laser tubes on) |
||
|
Power indicator |
Backlight of horizontal bubble locator is ON |
||
|
Charge indicator |
radic |
||
|
Low power indicator |
radic(Backlight of horizontal bubble locator is flashing) |
||
|
Power supply adaptor |
DC 4.5V |
||
Note:
If the device is out of level, the laser will be shut down automatically with audio alert.
1. Rotate the power switch clockwise to turn on the device. Laser beams are emitted with the green LED ON.
2. Rotate the device to make the laser beam pointing at the target.
3. Turn the thumb screw to locate the exact position.
4.After every task, turn the power switch anticlockwise to turn off the device.
5.Technical specifications
Package Content:
1 x Laser level
1 x Lithium Battery
1 x Kit box
1 x Strap
1 x Goggles
1 x Target Card
HYJ
2019-3-29
