Material: ABS

Type: Bluetooth Car Handsfree

Applicable phone models: with Bluetooth phones

Mounting: cigarette lighter style

Output: FM

Input voltage: 12-24 (V)

Weight: 70

Storage Capacity: No memory

USB Output: 5V / 2.1A

Bare metal weight: 47g

With packaging Weight: 73.5g

Size: 7.3X4.5X9.5CM

Box Size: 8.5X9X5.5CM

Battery: This product is "free" battery, to facilitate air transport

Product List: Host + English manual + carton packaging

Bluetooth Car MP3 Product Description

Thank you to select and purchase the company's Bluetooth MP3 products, give full play to your use of this product's functions operating properly, please read the manual before using!

one. Product Description:

This product is a special car Bluetooth Car Charger MP3 player and an FM transmitter, high-performance professional-grade Bluetooth module, built-in MP3 / WMA decoder chip, the memory card can play music files transmitted to the car stereo via FM radio. If you are using a mobile phone with Bluetooth link usage, calls can be automatically switched to the speakerphone state, end the call and then automatically switches back to the music player, you can also launch your way through the music phone into a wireless transmitter your car stereo. The product with embedded echo canceling microphone, with just one button you can easily switch between music and calls. You do not need to modify your car will be able to enjoy music and hands-free phone.

two. Product schematically illustrates

1. Rotate button Volume subtraction / down song / CH + CH-

2. Multi-function button is pressed for the spin button multi-function button. Answer / end / redial phone / Play / Pause

3. Mode button down song mode, FM frequency adjustment mode, adjust the volume, the phone call switch language switch

4. Call reject, disconnect the Bluetooth

5. LINE OUT Audio output hole

6. Bluetooth status indicator

7. microphone

8. TF card slot

9. USB charging hole

10. The display window

Third, the product features:

1: Adjustable any angle for all types of vehicle use

2. Support Bluetooth 4.0 / 3.0 / 2.0 devices. Supported operating voice prompt support to cable

3. Support Android and Apple phones and other devices USB charging, the maximum output current of 2.5A

4. Support Full frequency FM transmitter function, a total of 208 frequency points

5. Support digital display

6. Support external TF card MP3 / WMA music format player

7. Support answer, hang up, reject, call-back telephone functions

8. support the call echo cancellation and noise suppression (CVC) technology

9. supports automatic power-off memory function

10. supports Bluetooth stereo music player

four. Product Instructions:

5.1 Bluetooth pairing mode and connection

5.1.1 The host cigarette is inserted into the base point, the product automatically after power is turned on if there is no memory card detection TF card slot will automatically enter the Bluetooth mode (the voice prompt "Pairing Bluetooth Ready"); If the test there are inner TF card slot memory card into the memory card will automatically enter the playback mode, then press the button for two seconds to grow by converting the Bluetooth mode (the voice prompt "pairing Bluetooth ready")

5.1.2 The machine boot into Bluetooth mode, LED display shows the current FM transmission frequency. Bluetooth status automatically search for the red and blue Bluetooth status lights flash alternately

5.1.3. The status of the Bluetooth pairing will automatically search for and it has previously been paired phone will automatically if the link is in the range (in this case a voice prompt "Bluetooth pairing success"). If no phone has been paired in the search range you will need to re-pair the new phone

5.1.4. The first time you use your phone with a Bluetooth hands-free link pair your phone with a Bluetooth handsfree need the code to connect.

5.1.5. In the Bluetooth handsfree turned on, the phone's Bluetooth feature is set to ON state, and to search for "FM01" device displayed on the phone.

5.1.6. Select "FM01" equipment and automatic matching (At this point a voice prompt "Bluetooth pairing success").

5.1.7. Call

In the Bluetooth phone link status, directly from your phone by phone number and then make a call, the sound emitted from the automatic car stereo speakers ..

5.1.8. Receiving calls

In the Bluetooth phone link state, when a call comes in when the direct key to answer the call, the call is connected, press the mode button and the machine can achieve a mobile phone microphone microphone switch, call button to hang up the phone

5.1.9. Refuse to answer the phone

When a call comes in time but do not want to answer, you can reject an incoming call button

5.1.10. Redial phone

In the Bluetooth phone link status, double-click the button to automatically redial the last call number

5.1.11. To cable

When a call comes in, automatically broadcast voice caller ID

5.1.12. Play music stored in the phone

The product supports A2DP feature, you can play music stored in the phone, and transmitted to car audio via Bluetooth hands-free FM, used to reduce higher-quality sound effects. During music playback short key play / pause function, rotate the knob to the right "under a" knob to the left "on the song"

5.2. TF memory card music mode

5.2.1. The host into the cigarette lighter of the base, the product automatically after power is turned on. If you have a memory card into the memory card will automatically enter the music playback mode in the detection TF card slot (this time a voice prompt "MUSIC"). LED display shows the current FM transmission frequency

5.2.2. During music playback short key play / pause function, rotate the knob to the right "under a" knob to the left "on the song"

5.2.3. Conversion Bluetooth link and memory card playback. With the power button to switch to the Bluetooth link long, long button again reversed TF card player. This button to cycle to achieve the two modes

5.3. FM receiver

5.3.1 Open consistent reception frequency to the car stereo FM radio mode, adjust the transmission frequency of car audio and car radio, you can play out from the car stereo music or talking machine.

5.3.2 adjust the transmission frequency. Short press mode button, the screen bounces "FRE", this time turning the knob to achieve emission frequency up / down, the machine can be adjusted from 87.5 ~ 108MHZ transmission frequency.

5.4 System volume adjustment

The system volume is 30, it is recommended to adjust the level between 20-25. Short press mode button, the screen bounces "U + number", then turn the knob to achieve the system volume up / down

5.5. System prompt language

This product is built-in Chinese and English languages, press mode button to hear "drop" soon after the two languages Cycle

5.6. USB charging

This product provides a USB output port, supra Fig. 9 position. Can give mobile phones and other digital products charge, supports output 5V / 2.5A (maximum)

5.7 audio output mode:

The product supports audio output, see figure 5 position. When the machine detects the audio cable into the automatically stopped when the FM transmitter, then the music and phone through the audio output port

5.8 Power and memory:

For your convenience, in general, every time you use the product after power failure, the system will automatically remember your first time playing this track and transmit frequency information, and then use the next time to start playing from the track, but when after you remove or replace the storage device or the system detects an error situation the system will automatically return to the first song starts playing.

Fives. Technical Parameters

Rated working voltage

  12V --- 24V

Operating voltage limit

  9V ----- 28V

USB Output

  5V / 2.5A

Memory card playback formats

  MP3 WMA WAV FLA

Bluetooth version

 Bluetooth V2.1 + EDR baseband and modem

Bluetooth transmission distance

  10M

Bluetooth transmitter power

 class2 and class3

Bluetooth receiver sensitivity

 -85dBm Sensitivity

SNR

 SNR> 93dB

Microphone effective range

  0.5 --- 2M

Operating temperature

  0 to 50 degrees

Distortion

  <0.1%

Frequency response

  20Hz-15Khz

FM transmission frequency

  87.5 ~ 108Mhz

FM transmit mode

 Stereo digital PLL frequency lock

 six. Precautions

1. This product is only as a charge to use the USB port can provide a maximum output of 5V / 2.5A. Do not use a high-power electrical equipment or power inverter to avoid damage

2. In Bluetooth mode search link phone, make sure the phone is in the normal range and the Bluetooth mobile phone in pairing state

3: To insert TF memory card status, the memory card is in play state priority, if you want to link a Bluetooth need to adjust the play mode, see 5.1.1 or 5.2.1

4. When the unit volume in FM transmitter will not be too big (generally 25 or lower position), in order to avoid sound distortion, adjust the volume using the car stereo adjustments.

5. Native FM transmitter built-in antenna, when used should also try to avoid strong local radio frequency signals in order to get better sound quality

6. Due to various differences in the phone itself, in practice the use of Bluetooth in the method may vary

7. In the player after power off, and some models of mobile phones may not automatically connect function, using the manual connection.

8. Although this product is compatible with the current market more than 95% of the major brands of mobile phones, but there are still some phone are not compatible, at the time of purchase please note.

9: During a call, volume adjustment should be moderate, not too large, so as not to affect each other's call results.

10. Do not use this product in temperature is particularly high or low and dusty, humid environment.

11. Do not allow the product to fall, so as to avoid surface damage or damage to the machine

12. This product should be unplugged from the long-term without the car cigarette lighter hole. Normal should be used such as automotive ignition before inserting use. Avoid ignition voltage is too high and damage.
