Kingdel Fanless Mini PC Windows10 Processor Intel Core i7 5550U i5 4200U i3 5005U/5010U Nuc Computer 4K TV Box DHL Free Shipping |

---

Notice: In Aliexpress and DHL system, Canary Islands is different from Spain as well as Reunion from France so that shipping cost is also different. If you are from those two places, please choose your order destination as Canary Islands or Reunion instead of Spain or France when placing your order, otherwise your order won't be processed until shipping cost gap is made up.   Thank you! Kingdel Team



Fanless mini PC, HTPC

Intel Core i7 5550U up to 3.0GHZ,Dual Core, 4M Cache,TDP 15W DDR3 RAM, MSATA SSD ,WiFi, 4*USB 3.0, 1*VGA, 1*HDMI  Intel HD Graphics6000, Fanless,Full Metal Case

This mini pc motherboard can install 3 types of processors:

1. CPU 14nm Intel Core i7 5550U 2 core 4 threads 4MB cache 2.0GHz Max 3.0GHz TDP 15W Graphics HD 6000. 2. CPU  22nm Intel Core i5 4200U 2 core 4 threads 3MB cache 1.6GHz Max 2.6GHz TDP 15W Graphics HD 4400. 3. CPU 14nm Intel Core i3 5005U 2 core 4 threads 3MB cache 2GHz TDP 15W Graphics HD 5500.   Kindly Reminded: 1, This computer only works with RAM at lower voltage 1.35V instead of normal 1.5V RAM. 2, Warranty is 3 years for Barebone PC, 1 Year for RAM and Storage. 3, The RAM and SSD/HDD are from famouse brand, the RAM is normally Sam'sung, Elp'ida, Hynix; The SSD is normally from Tosh'iba, Sam'sung, ADATA, Intel, Lite-on etc. they will be shipped out at random for stock. 4, The Operating System is just for testing, copied and activated but not licensed, please install the licensed one by yourself if you prefer. 5, Please carefully read the SHOPPING GUIDELINES    on the bottom of this page. It is regarded as you have agreed all listed when you place an order. We won't take responsibility for any problems might caused except the quality problem of the product.

Thank you !

Windows 10 Desktop:

Branded Spare Parts, Boyscott Fake Parts!!

Top Quality, 3 Year Warranty, Rest Assured!!

1, Quality Approval:

2, Product Advantages: 1. Special: 64 bits computing,  Hyper-Threading technology, Virtualization technology; Support Wake-On-Lan; Support calls on function automatically;  Support SSD and HDD together, up to 512 SSD and 1TB Hardisk large volume; Support Max 16GB DDR3 RAM, 2 RAM Slot; I/O port: 1 VGA, 1 HDMI, 1 LAN, 4 USB*3.0, 2*USB2.0 2. Stable: Intel Braodwell-ULT +Intel HD Graphics 6000+Fanless 3. Smart: Fanless system, smart design, no noise, be able to work 24hours per day 4. Slim: Only 4cm body thickness, brushed black alloy case 5. Smooth: Support 3D games, blue-ray and HDMI 4K HD streams, full 1080P playback 6. Strong: Work for multiple application. For example: integrated with touch devices, industries, car repair shops, security, education, home as HTPC, business, fanancial and projector, Hotel.   3,Key Features:  RAM: Support DDR3L-1600; max expanded to 16GB SODIMM Notebook memory;      Storage: max expanded to 1*mSATA3 SSD and 1*2.5 inch laptop SSD/HDD SATA3, no limited on storage capacity;   Operating System: Default: Windows 10 Pro; Optional: Linux Ubuntu      Wireless: 300MB WiFi with 2 Antennas      I/O: 1*HDMI, 1*VGA,  1*LAN Gigabit (RJ45),  4*USB 3.0,  2*USB2.0 Internal ports: 1*mSATA3.0, support 6Gb/s, 1*SATA3.0, support 6Gb/s, 1*mini-PCIE port (for WIFI);       HD Out put: 1*HDMI, support HDMI to DVI and HDMI to VGA      LAN port: 1*Gigabit RJ45 port speed up to 1Gbps;

Case Material: Brushed Aluminum Alloy;

    Product Specification:   Processor                 Intel® Core™ i7-5550U Processor                                 Dual Core Quad Threads                                 Base Frequency 2.00 GHz, Max Turbo Frequency 3.00 GHz                                 14nm Lithography                                  Intel Broadwell-U Chipset                                 4MB SmartCache                                 15W TDP                                 Multimedia Instruction Set: 64-bit; MMX, SSE, SSE2, SSE3, SSE4.1, SSE4.2, AVX Processor Graphics  Intel® HD Graphics 6000                                 Graphics Base Frequency 300.00 MHz                                 Graphics Burst Frequency 1.00 GHz                                 Graphics Video Max Memory 16 GB                                 Max Resolution (HDMI 1.4): 2560x1600@60Hz BIOS                         AMI BIOS, ACPI supported RAM                         16GB; 2gb/4gb/6gb/8gb optional, 2*DDR3 SO-DIMM SDRAM Slot Storage                    64GB/128GB/512GB SSD & 500GB/1TB HDD available Operating System     Default: Windows 10 Pro; Optional: Windows 8.1, Windows 7, Linux Ubuntu Audio Card                ALC892 sound chip, 6-channel Network Card             RTL 8111E 10/100/1000 BaseT LAN Wireless                    Wifi 802.11.b/g/n, 300M, Dual Antennas; Bluetooth 3.0 optional I/O Port                     1*HDMI, 1*VGA, 1*RJ45 LAN Port, 4*USB3.0, 2*USB2.0, 1*DC IN, 1*MIC, 1*SPK SATA                        1*mSATA3.0 Slot, 6Gb/s; 1*SATA3 Connector, 6Gb/s MINI PCIE                 1* MINI PCIE Slot for Wifi Module (Half Size) Power In:                    DC100-240V AC/50-60Hz Out: DC 12V/3A Operating Temperature  0°C~70°C (32°F~140°F) Storage Temperature     -20°C~80°C (-68°F~176°F) Relative Humidity        10%~90% (non-condensing) Size                           197mmx 197mmx39mm Weight                       about 1.5kg Package Content         Mini PC, Power adapter, Power Cable, Wifi Antennas, Stand Bracket, Screws     Application:   - used as HTPC (Home Theater Personal Computer). Connect HDTV with the HDMI cable, you can enjoy education online and play internet movies or games. -used as Personal Computer, high configuration and fast speed, zero noise. - Internet Bar. High speed Gigabit Ethernet and diskless certificate, support 3D games. - Factory, classroom, bank, supermarket, manager rooms, stores. - used in Library, reading room, hotel, training, call center, CCTV company.





     VESA Mount costs extra USD5, Please click the picture to pay together if you need:

Processor	Intel® Core™ i7-5550U Processor
	Dual Core Quad Threads
	Base Frequency 2.00 GHz, Max Turbo Frequency 3.00 GHz
	14nm Lithography
	Intel Broadwell-U Chipset
	4MB SmartCache
	15W TDP
	Multimedia Instruction Set: 64-bit; MMX, SSE, SSE2, SSE3, SSE4.1, SSE4.2, AVX
Processor Graphics	Intel® HD Graphics 6000
	Graphics Base Frequency 300.00 MHz
	Graphics Burst Frequency 1.00 GHz
	Graphics Video Max Memory 16 GB
	Max Resolution (HDMI 1.4): 2560x1600@60Hz
BIOS	AMI BIOS, ACPI supported
RAM	16GB; 2gb/4gb/6gb/8gb optional, 2*DDR3 SO-DIMM SDRAM Slot
Storage	64GB/128GB/512GB SSD & 500GB/1TB HDD available
Operating System	Default: Windows 10 Pro; Optional: Windows 8.1, Windows 7, Linux Ubuntu
Audio Card	ALC892 sound chip, 6-channel
Network Card	RTL 8111E 10/100/1000 BaseT LAN
Wireless	Wifi 802.11.b/g/n, 300M, Dual Antennas; Bluetooth 3.0 optional
I/O Port	1*HDMI, 1*VGA, 1*RJ45 LAN Port, 4*USB3.0, 2*USB2.0, 1*DC IN, 1*MIC, 1*SPK
SATA	1*mSATA3.0 Slot, 6Gb/s; 1*SATA3 Connector, 6Gb/s
MINI PCIE	1* MINI PCIE Slot for Wifi Module (Half Size)
Power	In: DC100-240V AC/50-60Hz Out: DC 12V/3A
Operating Temperature	0°C~70°C (32°F~140°F)
Storage Temperature	-20°C~80°C (-68°F~176°F)
Relative Humidity	10%~90% (non-condensing)
Size	197mmx 197mmx39mm
Weight	1.5~1.65kg
Package Content	Mini PC, Power adapter, Power Cable, Wifi Antennas, Stand Bracket, Screws
