10pcs/lot 6V 12V 24V 3A 80W PWM DC Motor Speed Controller, Forward Reversible Switch PWM parts DC motor accessories

About 1203bb:

Main Usage: widely use to people DIY, hobby, scientic test, such as control computer Ipad fan speed, control bulb, control motor kymco, control xbox360, HHO Pluse Width modulator, Test Equipment, industrial automation, speed regulator module board support PLC, motor electric pump fan speed control, PWM HHO RC controller,remote control toys, etc......

Features:


PWM Regulator 6V 12V 24V 28V 3A 80W Control Reversible DC Motor Speed Switch Controller using a Pulse-Width-Modulated (PWM) DC voltage with a Duty Cycle fully adjustable from 0%-100%.

The motor speed controller can easily provide a continuous current of3A to your DC motor or other DC load.

Main technical parameters:

l Input supply voltage: 6V-28VDC

l The maximum output power: 80W

l The maximum continuous output current :3A

l Duty Cycle adjustable: 0%-100%

Specifications:

l Item size: 32*50*11mm

Operating instruction:

1.  Connect your DC motor (or DC load) to the motor terminals as indicated on the wiring diagram.

2.  Connect a voltage of 6V-28V DC to the circuit making sure of the correct polarity of the connection. Note that the voltage applied to the motor will be supply voltage applied to the circuit.

It is recommended to add an

appropriately rated fuse in line with the positive supply in order to protect the circuit from any possible short circuits.

3.  You can now control the speed of the motor through potentiometer.

Positive inversion switch is used to control the motor speed direction. And the center position of positive inversion switch will cause the motor to stop.

Important Notes

   An appropriately rated fuse (rated a little higher than the maximum current you expect to draw) is recommended to ensure safe operation.

   The controller is NOT reverse-polarity protected and will be damaged if connect the supply voltage with wrong polarity. Double check all connections before applying power and always turn off the power supply before making any wiring changes.

Main technical parameters:

• Input supply voltage: 6V-28VDC

• Item size: 1.3*2*0.4 inches; Net Weight:1.13 ounces

• Duty Cycle adjustable: 5%-100%,potentiometer with

       switch function.

• The maximum output power: 80W

• The maximum continuous output current :3A

Operating instruction:

Before you attempting to wire the controller, make sure power is off.

WARNING: DO NOT REVERSE POSTIVE AND NEGATIVE POWER LOADS.THIS WILL DAMAGE THE CONTROLLER.

1. Connect wires refer to the "wiring diagram" .

2. Turn on the power, and adjust the potentiometer.

3. The LED indicates the power up and the speed of motor.

Pictures for refference:
