Product instroction

The company receives the remote control board, suitable for security alarm, remote control electric doors and Windows, signal control, industrial control, the electric control circuit of lifting equipment, etc. All remote control switch module, relay contact output independently, is very suitable for direct control of various load; Products adopt wireless fixed code technology, omnidirectional, noninterference switch. 12 v remote control switch, the power supply proposal with more than 500 ma dc regulated power supply.

Applicable scope

The intelligent microcessor intelligent control,can be used in garage door control,lighting control,remote control curtains,access control systems,motor control system,easy to install l and reliable.

Receiver every road can load maximum 3A current, can be directly driven each relay with a set of normally open normally closed contact. To prolong the service life of receive board, we don\'t recommend control high power load, suggested that every channel control power in the 500 w (impedance load); 300W (inductive load); 100W (below the motor load).

The basic parameters:

Operating voltage: DC12V

Working frequency: 315 MHZ

Contact capacity: 5A / 250VAC or less; 10A / 125VAC or less; 20 or less A / 14 VDC

Receiving sensitivity: > 105DB

Remote distance: 100 m (clearing no interference) the distance of the open distance without interference theory, using the interference and partition according to different environment. Typically 10% of the nominal range - 50%.

Control way: 1 normally open normally closed contact

Code type: fixed code; Bonding pad coding

Receiving plate size: 42 * 32 * 15 mm

Way of working: (if the option is to move, just put the jumper wire to delay location, and then transferred to the minimum delay time, it is to point to move)

Jog: press the remote control every key, corresponding relay connected, loosen the key remote control; The corresponding relay disconnect.

Interlock: hand press a key, the corresponding corresponding relay is switched on, then press another remote control; Relay disconnect.

The remote control parameters:

Working voltage: 12 v ( 23A battery (1)

Frequency: 315 MHZ

Launch distance: 100 m (empty) (by using environment is different, the distance to mark of 10% - 50%)

Encoding types:fixed code fixed form password code need to welding code

Dimension: 55 mm * 30 mm x 14 mm

Vibration resistance: 4.7 M

NOTE : if you are not professionals.Afer you order it.please tell me what working way do you need? Jog ,inter-lock,we will make sure them work before shipping to you thanks for your understanding, patience and support
