Лазерный гравер Master 2S 32-битный Max 810*460 мм ЧПУ гравировка резка приложение беспроводной резчик DIY логотип маркер принтер

Лазерный гравер Master 2S 32-битный Max 810*460 мм ЧПУ гравировка резка приложение беспроводной резчик DIY логотип маркер принтер

Choose [ Ships From China ]
We will ship from [EU Warehouse ]
VAT Tax is inclusive

Free shipping ,Fast Delivery in 3~5 days

Buy Max A40640 free air assist receive

Structure

Frame Size (L - W -H): 590x980x160mm
Working Size ( X - Y): 460 x 810mm, area extended design
Dot Pitch: 0.075mm
Pixel: 6133 x 10800 px
Frame Material: All-aluminum alloy and PC material hybrid frame
Structure Technology: Y-axis fit adjustable design, X-axis stress fit assembly
Structure Feature: Fit, High precision, stablize, smooth, no oil, easy maintenance, long life
Vertical Carving: Yes
Motor Size: 42 x 42 x 40mm
Motor Drive Current: 0.9A
Module Height Adjuster： Yes
Limit Switch: Yes
Home: Rear Left
Origin: Front Left
Max Move Speed: X:1000mm/s,Y:750mm/s(with A40640 module 204g)

Control System

MCU: 32-bit MCU
BLE: Yes
MEMS: Yes
Input: 12V 5A
Compatible Modules: All NEJE 12V 4pin Laser Moudle
ON/OFF Switch：Yes

Software Service

OTA Upgrade:Update NEJE firmware, GRBL firmware, update latest software via NEJE Win software.
LaserGRBL: Yes, Added low light function, added M8, M7, emergency stop extended automatic control, optimized GRBL interaction.
LaserGRBL: Yes, Added low-light display and can be adjusted, added M8, M7, Door function automatic adaptation.
NEJE Win Software: Yes, It is recommended to open the NEJE software to update to the latest firmware for the first time use.
Off-Line Working:Yes, In NEJE Win software and NEJE APP mode, when the image is transferred to the device, it can work independently from the computer or mobile phone.
Repeat Engraving:
Yes, After the engraving or cutting is completed, the device will not lose the location information, if you are not satisfied with the work, you can continue to work.
NEJE Android APP: Yes
NEJE iphone/iPad APP: Yes
NEJE Cloud Gallery Service: Yes
Software Download: //neje.wiki

NEJE A40640 Laser Module

Radiator Size: 40 x 50 x 60 mm
Weight: 204g
Speed of the Fan: 10600RPM(Double ball bearing)
Interface: PH2.0 4Pin
Drive Design: Built-in
Input: 12V 4A +
Optical Power: 10W +
Wavelength: 450nm
Laser Class: Class 4
Number of Diodes: 2
Light Source: 2 X LD + FAC Tech + C-Lens
Focus Spot ： o.13x0.13mm - 0.18xo.18mm,
focus on 33mm: 0.13 x 0.13 mm,
focus on 55mm: 0.18 x 0.18mm
PWM Input: VPP(3.3-12V), Recomend 1KHz,
Quiet Design: Drive the built-in control ic, judge the working state and adjust the fan work.
Max Cutting & Carving Depth: 18mm (The data is tested by NEJE users, and it needs to be done under more accurate focusing and adding correct and certain strength of air assist.)
Brushed Stainless Steel: Yes
Mirror Stainless Steel: Yes

Warranty

Laser Module Warranty: 2 Years
Control system warranty: 2 Years
Hardware warranty: 1 Year

Note (please note):

The conditions of NEJE's free after-sale policy must be met under the conditions of non-human disassembly and misoperation and use in the correct environment. If the wrong voltage is input, or the lens is damaged due to lack of maintenance, it is not within the scope of free after-sale; for maintenance instructions, please refer to NEJE.WIKI

NEJE 3 MAX A40640 Package List：

1x NEJE 3 Max Machine
1x A40640 Laser Module with air Assist Kits
1x 12V 5A standard certified power adapter
1x USB Cable + Manual + Quality Card
1x Goggles x 1
1x L-shaped Crawler Aluminum Profile
2x Crawler x 2
1x 12V Valve Control Kit (less than 1.5mpa)
1x 12V Relay Expansion Control Kit (Extra AD or DC power Max 2500W)
1x 1 Meter Door Control Kit
1x Screw Nut Wrench Screwdriver Belt Installation kit
1x Test Material kit

NEJE 3 MAX N40630 ：

1x NEJE 3 Max Machine
1x AN40630 Laser Module with air Assist Kits
1x 12V 4A standard certified power adapter
1x USB Cable + Manual + Quality Card
1x Goggles x 1
1x L-shaped Crawler Aluminum Profile
2x Crawler x 2
1x 12V Valve Control Kit (less than 1.5mpa)
1x 12V Relay Expansion Control Kit (Extra AD or DC power Max 2500W)
1x 1 Meter Door Control Kit
1x Screw Nut Wrench Screwdriver Belt Installation kit
1x Test Material kit

A40640 small kit packing list:

N40630 small kit packing list:
